8.3.2 S
ERVER
RS232 interface for connection to a PC Server running the Voltech AT Series
Server software.
25-pin male D-type connector.
Pin
1
2
3
4
5
8.3.3 A
UXILIARY
RS232 interface for connection to a PC running the Voltech AT Series Editor
software.
9-pin male D-type connector.
Pin
1
2 o/p
3 i/p
4
5
V AT U
OLTECH I SER
P
ORT
Signal name
Ground (Earth)
i/p RX
o/p TX
i/p CTS
o/p RTS
P
ORT
Signal name
No connection
TX
RX
No connection
0V
M
ANUAL
Pin Signal name
6 No connection
7 0V
8 No connection
...
25 No connection
Pin Signal name
6 No connection
7 i/p CTS
8 o/p RTS
9 No connection
