G S
ETTING TARTED
during boot-up at the general information screen will reset all tester options to
the factory defaults, including screen contrast, screen background and beep
volume, excluding the real-time clock.
The factory default settings are:
Option
FAIL Beeper
PASS Beeper
Key Response
Beeper Volume
Display Contrast
Display Background
Touch Pad Option
Pad Response
Program Store

2.9.2 Groups Softkey

When the tester is set up to use the INTERNAL program store, and after you
have entered the part name, it will search for that name in the programs that
are stored in its own, non-volatile RAM. To store these programs, you must
use either the 'group download' or 'tester download' features described here.
Group Download Using the Server
Before attempting to download a group of programs, ensure that the Server
software is running on its PC, that the lead is connected from the tester's
Server port to the Server PC, and that the COM port is correctly set up in the
Server.
Also ensure that the group you wish to use has been created within the Server.
(From the Server top-level menu, select 'Setup', 'Groups', etc., as explained in
chapter 4).
P 2-84
AGE
Default Setting
OFF
OFF
CLICK
6
8
LIGHT
L AND R
CLICK
INTERNAL
V
OLTECH
AT U M
I SER ANUAL
