F
IXTURES
5.4.2 C
USTOM
A kit of parts for constructing your own fixtures. Interconnecting wire, test
probes or clips and a drilling template will also be required. The custom fixture
kit comprises:
Item 1
Item 2
Item 3
Item 4
Item 5
Fixings for above.
5.4.3 S
OCKET
A fixture board fitted with 40
4mm sockets. 20 red (power)
and 20 black (sense). The
sockets are wired to the 40
contacts, which align with the
tester's 40 nodes.
This fixture may be used for
convenient wiring to existing
fixtures or as a means of connecting flying leads and clips for use in
developing test programs or testing parts in a design laboratory.
P 5-16
AGE
F K (V
IXTURE IT
Base plate (including contact pins) with cover
Test piece interface plate
Probe housing box
Bezel
Guides (12 off)
F (V
IXTURE OLTECH
P N
OLTECH ART UMBER
P N
ART UMBER
V
91-185)
91-186)
