Resp Frequency Response; Ilos Insertion Loss; Rlos Return Loss; Reactance - Voltech ATi User Manual

T T
ESTS AND EST
Test Description
ILOS Insertion Loss
RESP Frequency Response
RLOS Return Loss
Z Impedance
ZB Impedance with Bias
ANGL Impedance Phase Angle
PHAS Interwinding Phase Angle
X

Reactance

TRIM Trimming Adjustment
OUT Output to User Port
Inductance with External
LSBX* Bias (Series Circuit)
Inductance with External
LPBX* Bias (Parallel Circuit)
Impedance with External
ZBX*
Bias
Check www.voltech.com for the latest list of available tests.
Each test is described in detail in the following pages, together with
programming guidance for use with the Voltech PC Editor.
P 7-10
AGE
C
ONDITIONS
Transformer Application
Audio & telecom
Audio & telecom
Audio & telecom
Audio & telecom
Audio & telecom
Audio & telecom
Measuring & signal
Audio & telecom
Transformers with variable
/ trimmable components
Wound components that
usually carry a significant
DC Bias current in normal
operation.
Wound components that
usually carry a significant
DC Bias current in normal
operation.
Audio & Telecom
Reason for Test
Checks power lost within
the transformer
Checks losses over a
range of frequencies
Checks power returned
by a transformer
Checks impedance at a
given frequency
Checks impedance at a
given frequency
Checks phase angle of
complex impedance
Checks phase of voltage
between windings
Checks imaginary part of
the complex impedance
at a given frequency
Adjusts transformer
parameter to desired
value during test
Performs external
switching as part of the
test program
Checks number of turns,
right grade of correctly
assembled core
material, where bias
current is greater than
LSB test can handle.
Checks number of turns,
right grade of correctly
assembled core
material, where bias
current is greater than
LPB test can handle.
Checks impedance at a
given frequency, while
applying a greater bias
current than is possible
with ZB test.
