P
ROGRAM EDITOR
4. Have available both a sample transformer, and possibly a shorting
header if you wish to add tests to the program for which you will be
applying short-circuit compensation.
.
3.4.2 E
XAMPLE OF
LS - Winding Inductance (Series Circuit) - is one of the tests where both the
test voltage and frequency, and the actual measurement may be obtained by
using the Measure button. The following example assumes that this is what
you wish to do.
Initially select the LS test in the normal way by double-clicking with the mouse
in the Available Tests list.
In the LS test dialogue box:
Enter the terminal names in the normal way.
Select the integration you require if different from the default setting of
Medium.
In the Test Parameters section, leave both the Signal and the Frequency edit
boxes blank.
The default units button for the Signal is 'mV'. With this setting, the Editor will
enter the test voltage chosen by the tester, changing as appropriate to the 'V'
button if the signal is large. Alternatively, if you wish the test signal to be
determined as a current, click on the 'mA' units button.
Finally, in the lower section of the dialogue box, select the desired limits type.
