8.3 I
NTERFACE
The following interfaces are available at the rear of the ATi:
From left to right:
Barcode – Server – Printer – Auxiliary (Editor) – Remote – User – Ground
!
All these ports may be susceptible to damage from static discharge.
Switch off and observe anti-static precautions when making
connections.
8.3.1 B
ARCODE
V AT U
OLTECH I SER
D
ETAILS
P
ORT
RS232 interface for barcode entry
9-pin female D-type connector
Baud rate: 9600
Parity: None
Stop bits: 1
M
ANUAL
S
PECIFICATIONS
P 8-25
AGE
