The "User Offset Enabled" check box has the same function as before
but in units of inductance.
Click on the 'OK' button. Again, the test and its parameters will appear
in the 'Program' window.
7. Finally, by double-clicking the left mouse button, select 'TR Turns
Ratio' from the 'Available Tests' window.
At the dialogue box, enter the data required for the turns ratio test:
The AT measures the turns ratio between 'primary' and 'secondary' windings;
and allows the possibility of applying the test voltage to a third 'energized'
winding. For this example, the primary and energized windings are the same:
Energized high terminal
Energized low terminal
Primary high terminal
Primary low terminal
Secondary high terminal
Secondary low terminal
Using the default ' % ' type of limits, enter:
Primary: Secondary
Neg
Pos
V AT U
OLTECH I SER
Voltage 1V
Frequency 50Hz
Integration (Leave as the default - Medium)
M
ANUAL
A
B
A
B
C
D
1:1
2%
2%
