The ATi is very easy to use. However, it is a complex instrument, which can be
installed and operated in many ways.
In order to maximize the benefits that the ATi can bring to your test
environment, please study the following section carefully.
1.6 T
YPICAL
Editor PC - used only when creating
or editing test programs.
Untested
transformers
Manual or robotic operation
• Barcode input
• Run-pad or footswitch to initiate operation
• Simple PASS/FAIL operation by an unskilled operator
Results
• Direct printing from the ATi printer port
• Results archiving to disk using the Server application
• Results for analysis can be easily exported to other Windows applications
