S P E C I F I C A T I O N S
10.3.
Interface Specifications
10.3.1.
RS232 interface for connection to a PC server running the Voltech server
software.
25-pin male D-type connector
Pin
1
2
i/p
3
o/p
4
i/p
5
o/p
As RS232 is now a legacy protocol for communications, it's it highly likely that
customers using RS232 on the AT5600 will use a USB to RS232 converter to
interface with your PC.
As the AT5600 generates high voltages and is commonly used in environments
where high voltage and EMC noise is present, we recommend using an optically
ISOLATED USB-RS232 converter.
Voltech recommends the STAR TECH converter
Model #
See
This is 1 Port Industrial USB to RS232 Serial Adapter with 5KV Isolation and 15 KV
ESD Protection
10.3.2.
RS232 interface for connection to a PC running the Voltech editor software.
9-pin male D-type connector
Pin
1
2
o/p
3
i/p
4
5
SEE ABOVE RECOMMENDATION (in 10.3.1) OF ISOLATED USB TO RS232 CONVERTER
AT5600 User Manual 98-119 issue 14
Server Port
Signal name
Ground (Earth)
RX
TX
CTS
RTS
ICUSB232IS
www.startech.com
Auxiliary Port
Signal name
No connection
TX
RX
No connection
0V
Pin
Signal name
6
No connection
7
0V
8
No connection
...
25
No connection
Pin
Signal name
6
No connection
7
i/p
CTS
8
o/p
RTS
9
No connection
