5.1 I
NTRODUCTION
AT Series Testers are able to perform an extremely comprehensive series of
tests on a wide variety of transformers. To utilize this capability fully, it is
recommended that test fixtures be constructed to suit each particular type of
transformer to be tested.
Test fixtures are based on a fixture board containing connector pins. They
provide the interface to the tester via the tester node pins, allowing
transformers to be quickly inserted and removed in a reliable manner, taking
full advantage of the high-speed testing capability of the tester.
i
V AT U
OLTECH I SER
A broad range of basic fixturing parts and fixture kits
are available from Voltech. In addition, complete,
ready-to-use fixturing solutions are also available from
Voltech's fixturing partners. Visit our website
(www.voltech.com) for the latest information.
M
ANUAL
F
IXTURES
P 5-5
AGE
