1.5 AT
The ATi tester is a fast, accurate and versatile automatic LCR meter.
FAST – Typically more than 10 DIFFERENT tests per second.
•
•
•
•
•
ACCURATE – 0.05% basic
•
•
•
•
•
VERSATILE
•
•
•
•
V AT U
OLTECH I SER
F S
I EATURES
20 way switch matrix.
Automatically switches from making measurements on one
winding of a transformer to another winding.
Measures across different windings.
No need to manually change connections.
Fast execution of a sequence of different tests on multiple windings
of a transformer.
Inductance from
Any frequency from
Any voltage from
AC constant current source
DC bias up to
Easy to use.
High-speed production tester.
Laboratory grade LCR meter.
Upgrades and new tests installed from disk.
M
ANUAL
UMMARY
1nH to 1MH
20Hz to 3MHz
1mV to 5V
20µ µ µ µ A to 100mA
1A
I
NTRODUCTION
P 1-11
AGE
