Description; Description - Voltech ATi User Manual

F
IXTURES
5.2 D
ESCRIPTION
The Voltech AT Series fixture system allows you freedom and flexibility when
considering your fixturing needs. All fixtures are mounted on fixture boards,
which are available as a blank fixture plate and also as fixture kit, which
contains parts to help you.
The following basic building blocks are available:
A. Fixture Plate
Designed for mounting existing
fixtures to an AT Series Tester.
Comprises:
Base plate (including contacts) with
cover.
Test piece interface plate.
P 5-6
AGE
B Custom Fixture Kit
A kit of parts for constructing
your own fixtures.
Interconnecting wire, test probes
or clips and a drilling template
will also be required.
Comprises:
Base plate (including contacts)
with cover.
Test piece interface plate.
Probe housing box.
Bezel.
Guides (12 off)
