5.4.4 C
ONNECTION
A selection of Kelvin and non-Kelvin crocodile clips and spring-loaded posts
are available from Voltech, called the 'Connection Lead Set'
Each of the 'clips' is finished with 200mm red and black leads terminated in
4mm plugs.
The connection lead set consists of:
5.4.5 C
LAMP
The hand clamp is supplied with 7
height blocks and fixings.
5.4.6 T
OOLING
Drilling templates are available in a variety of sizes (1.27mm, 2.00mm,
2.50mm, 2.54mm, 3.81mm) and are sold as a pack.
Pack of 5 (1 of each pitch) drilling templates. Voltech Part No. 50-307
V AT U
OLTECH I SER
L S
EAD ET
(V P
OLTECH ART
M
ANUAL
(V P N
OLTECH ART
10 Spring-loaded connection posts
10 Kelvin crocodile clips
10 Non-Kelvin crocodile clips
10 Fine non-Kelvin clips
N 91-187)
UMBER
78-030)
UMBER
P
AGE
F
IXTURES
5-17
