1.8.6 Operating the AT Series Testers in Production Test

The ATi is suitable for use in both manual and robotic production situations.
Manual Use – Testing Smaller Batches of Different Transformers:
Operator:
1.
2.
3.
Run/Stop/Fail/Busy
signals for process
control
Parts to be tested
before finishing
Touch pads or foot
switch to start the test
P 1-24
AGE
Chooses transformer part number from a list or swipes a barcode
Fits the fixture as prompted
Touches pad or presses footswitch
Remote PC records all test data
•
Quick connections to the transformer under test
•
Rapid change of fixture for different transformer types
for statistical analysis using
Voltech server software
Low cost fixture plates
Good parts for further
processes
Failed parts for
rejection or rework
