The base plate has moulded indents and guides to ease the fitting and wiring
of larger test sockets and posts for flying leads.
2. Probe Housing Box
This 9mm thick plate is designed especially to hold a wide range of ATE
probes and Kelvin pins.
3. Clamp
An optional hand clamp holds the test piece against the test probes. The
clamp is adjustable in height and in spring pressure. Voltech Part No. 91-187
4. Guides
12 adjustable guides are supplied to locate the test piece in the fixture quickly
and accurately.
5. Drilling Tools
5 different pitches of template are available for marking and drilling the holes
To enable the probe housing box and the test piece interface plate be drilled to
the accuracy required, drilling templates are available in the following grid
pitches:
Pack of 5 (1 of each pitch) drilling templates. Voltech Part No. 50-307
P 5-10
AGE
for test probes or Kelvin pins.
1.27mm, 2.00mm, 2.50mm, 2.54mm and 3.81mm
