F
IXTURES
5.2.3 40 S F
OCKET IXTURE
Red Terminal (Power)
Black Terminal (Sense)
Where Used
Ideal for developing test programs or testing small batches of different wound
components. The 40 Socket Fixture consists of 20 pairs of red and black 4mm
shrouded safety sockets mounted and wired into a blank fixture.
A variety of clips and posts can be used to enable connection to the
component under test.
When testing larger quantities of the same component (50 or more) then a
custom fixture solution is strongly recommended. Ask your Voltech supplier for
details of the Custom Fixture Kit.
V AT U M P 5-11
OLTECH I SER ANUAL AGE
