2.1.3 Other Data Inputs

To give you the greatest ergonomic flexibility, methods other than the
keyboard can be used to initiate testing and enter data.
Run-pads
Two stainless steel discs, at the front of each side of the ATi. Lightly touching
the programmable run-pads will start the programmed test sequence.
Footswitch
The 'Run' input of the 'Remote Port' on the tester's rear panel can be optionally
connected to a footswitch.
Barcode Input
A barcode reader connected to the 'Barcode Port' on the tester's rear panel
can optionally be used to input text data, such the name of the test program, or
the transformer batch or serial number of the transformer.
