If the TRIM test is included in a program, the behavior in production mode is
similar to the 'Stop on Fail' option described above:
If the test before the TRIM test produces a 'Pass' result, then the program
proceeds directly to the next test after the TRIM test.
If the test before the TRIM test produces a 'Fail' result, then the front panel
display will be similar to the following:
The main difference between this and the 'Stop on fail' display is that the
reading on the fourth line will be continuously updated, allowing adjustments to
be made to bring the test result within limits.
Pressing the 'Abort' softkey, again, stops the program and allows the operator
to throw away a transformer that cannot be adjusted to give a 'Pass' result.
After pressing the 'Continue' softkey, the remaining tests in the program will be
executed and, at the end of the measurement, the component will be classed
as a 'Fail'.
Pressing the 'Re-Run' softkey will re-start the test sequence from the
beginning.
