Introduction; Introduction - Voltech ATi User Manual

T T
ESTS AND EST
7.1 I
NTRODUCTION
Tests and Test Conditions
This chapter provides guidance for the use of each of the tests currently
available for the ATi. For the latest information please check the Voltech web
site at:
7.1.1 C
HOOSING
In order for a completed transformer to function properly in its intended
application, it should be constructed in accordance with the designer's
specification.
The test specification (or ATi test program) calls for various electrical
parameters to be measured such that the transformer construction is verified.
For example, a measurement of inductance will help to confirm that the correct
number of turns has been used with the correct grade of core material and that
the cores have been assembled correctly with the right air-gap.
To fully verify the transformer construction, however, a complete series of tests
should be carried out.
P 7-4
AGE
C
ONDITIONS
www.voltech.com
T
ESTS FOR A
T
RANSFORMER
V
OLTECH
AT U M
I SER ANUAL
