Voltech ATi User Manual page 141

After you have pressed the RE-RUN softkey, the tester will then be executing
a 'retry'. When results are sent to the Server, unless you have enabled the
program option 'Send Retry Results to Server', then no result will be sent to
the Server Results File except those for the final execution run, i.e. the one
that produces the pass or fail front panel display.
If you wish to see the measured results from each retry in your Server Results
File, then you should enable the program option 'Send Retry Results to Server'
when the program is created in the Editor. This option could provide data, for
example, which allows you to improve your production process and yield.
Notes
1. The third line showing the graphical comparison of the measured value and
user programmable limits has a logarithmic scale. The measured value may
be represented by either a vertical bar (as shown) when it lies within the
range that can be displayed on the LCD, or by an arrowhead (< or >) at the
end of the horizontal bar when it lies outside the range that can be displayed
on the LCD.
2. Should the tester be returning results to a PC running the Editor software,
then the Editor software will 'freeze' when this screen is displayed until the
appropriate softkey (Re-run, Continue or Abort) is pressed.
Program Edit
After you have created the program schematic, and selected the program
options, you may then start creating the actual program of tests.
To edit the test program, you must first switch to the Program Editor.
From the Top Level menu bar, select:
Program > Edit
