If the "User Offset Enabled" check box is checked, a value can be entered
into the edit box. The value entered (in the units shown) is then added to
any results returned from the AT tester.
•
Select OK. The test specification will now be displayed in the program
window.
Use the PC Editor's 'Measure' button (together with a sample part) if you are
unsure of how to choose the test conditions.
Choosing Test Limits
The test limits are the specific resistances for both X and Y terminals together
with + and – percentage limits.
Use the PC Editor's 'Measure' button (together with a sample part) if you are
unsure of the resistance values.
