2.1 I
NTRODUCTION
This chapter is designed to introduce you to the basic facilities of the ATi and
help you to realize the benefits of automated transformer testing in the shortest
possible time.
If you are reasonably familiar with the testing of transformers and how to install
and use Windows programs, this chapter may be all that you need, but you are
nevertheless urged to read and understand the complete contents of this
manual in order to achieve the maximum benefits that the ATi can bring.
For production testing, the use of good-quality test fixtures is very important.
Please see the fixturing section of this manual for details of parts that are
available from Voltech.
If you have any questions or are unsure of what to do at any point, please do
not hesitate to contact your Voltech supplier.
Once installed:
The ATi will enable you to rapidly, accurately and reliably test wound
components in your production or goods inwards environment.
The PC Editor will enable you to quickly and easily create test programs for
your tester, without any specialized knowledge of computer programming.
The PC Server will provide a storage system for archiving both the test
programs and the test results.
In this chapter, you will learn:
•
How to install the tester.
•
How to set up the Editor and Server software.
•
How to create and run a simple test program.
