Oracle Database Appliance X7-2M Service Manual page 50

Oracle Database Appliance X3-2/X4-2 Status Indicators
Callout
1
2
3
4
5
6
Storage Shelf Back Panel Status Indicators
The following figure shows the controls and indicators on the Oracle Database Appliance X3-2/
X4-2 storage shelf (DE2-24P) back panel and drives.
50 Oracle Database Appliance Service Manual • November 2017
Indicator/LED: Color
OK: green
Service Required: amber
Locate: white
Status Code Display
Drive Service Required: amber
Power/Activity: green
State Meaning
■ On – The storage shelf is powered on and operating normally.
■ Off – The storage shelf is unplugged or turned off.
■ Off – Normal operation.
■ Steady on – A fault is present in the storage shelf.
■ Off – Normal operation.
■ Fast blink – This LED blinks to help locate the system. Operators
can turn this indicator on and off remotely using Oracle ILOM.
■ Pressing this button toggles the fast blink on or off.
Not used for this product.
■ Off – Normal operation.
■ Steady on – A fault is present in the disk drive.
■ On – The drive is installed and recognized by the system but
there is no drive activity.
■ Blink – The LED blinks randomly in response to data being
written to or read from the drive.
■ Off – The drive is powered off or the installed drive is not
recognized by the system.
