Ethernet Port Naming And Boot Order - Oracle Database Appliance X7-2M Service Manual

See "Installing a Server Node Into the System Chassis" on page
Power on the server node.
c.
See "Powering On Oracle Database Appliance Version 1" on page
When the server node powers on and boots, it displays a message that indicates that
NVRAM has been cleared.
The CMOS NVRAM, including the BIOS password is cleared to its default state.
The default state for the BIOS passwords is that no password is required. To set a BIOS
password, see
Verify that the Power/OK LED is lit on the server node.
4.

Ethernet Port Naming and Boot Order

Information in this appendix does NOT apply to Oracle Database Appliance X3-
Note -
2, Oracle Database Appliance X4-2, Oracle Database Appliance X5-2 or Oracle Database
Appliance X6 series. Refer to the preceding chapters in this document for information on
servicing those systems.
Each Oracle Database Appliance Version 1 server node supports two 10/100/1000Base-T
Gigabit Ethernet ports on the rear of the chassis. For port locations, see the Oracle Database
Appliance Owner's Guide.
The device naming for the Ethernet interfaces is reported differently by different interfaces
and operating systems. See the following table for the physical (BIOS) and logical (operating
system) naming conventions used for each interface.
Interface
BIOS
Oracle Linux
The order in which the BIOS detects the Ethernet ports during boot time, and the corresponding
drivers that control those ports, are listed below:
1. NET 0 (INTEL NIC 0)
2. NET 1 (INTEL NIC 1)
Reset BIOS Password and Clear CMOS NVRAM Using CLR CMOS Button
"BIOS Security Menu Screen" on page
NET0
NET0
eth0
Appendix A • Servicing the Oracle Database Appliance Version 1
246.
249.
279.
NET1
NET1
eth1
259
