Oracle Database Appliance X7-2M Service Manual page 109

Oracle Database Appliance X6-2S/
X6-2M
For this product, the NVMe
Note -
Switch Card is located in Slot 2.
Servicing the internal host bus
adapter (HBA) (FRU)
Servicing the Disk Backplane (FRU)
Servicing the DVD Drive (FRU)
Servicing the Front Indicator Module
(FRU)
Servicing the Motherboard (FRU)
Servicing the SAS Cables (FRU)
Servicing the NVMe Cables (FRU)
The NVMe Switch Card
Note -
is located in PCIe slot 2 for this
product.
Servicing the Power, FIM, Disk
Backplane Data, and DVD Cables
(FRU)
"Component Fault
Management" on page 120
Servicing Oracle Database Appliance X6-2 Series FRUs
Oracle Database Appliance X6-2L
For this product, the NVMe
Note -
Switch Cards are located in Slots 2,
5 and 6.
"Servicing the Internal SAS
Host Bus Adapter (HBA)
(FRU)" on page 110
Servicing the Front Storage Drive
Backplane (FRU)
Removing the Rear Storage Drive
Backplane (FRU)
Installing the Rear Storage Drive
Backplane (FRU)
Note - For this product, there is
a single SAS cable that connects
directly from the PCIe HBA in slot
3 to the rear storage drive backplane.
It does not route through the chassis
mid-wall.
This product does not include a slot
for a DVD drive.
Servicing the Front LED/USB
Indicator Modules (FRU)
Servicing the Motherboard (FRU)
"Replace the Internal SAS HBA
Cables" on page 116
Note - For this product, there is
a single SAS cable that connects
directly from the PCIe HBA in slot
3 to the rear storage drive backplane.
It does not route through the chassis
mid-wall.
Servicing the NVMe Cables (FRU)
The NVMe Switch Cards are
Note -
located in PCIe slots 2, 5 and 6 for
this product.
For this product, cabling for Front
Indicator Modules and the disk
backplanes are included as part of
the FRU servicing procedure for
those components listed earlier in
this table.
"Component Fault
Management" on page 120
Oracle Database Appliance X6-2-HA
Servicing the internal host bus
adapter (HBA) (FRU)
Servicing the Disk Backplane (FRU)
Servicing the DVD Drive (FRU)
Servicing the Front Indicator Module
(FRU)
Servicing the Motherboard (FRU)
Servicing the SAS Cables (FRU)
This product does not have NVMe
devices.
Servicing the Power, FIM, Disk
Backplane Data, and DVD Cables
(FRU)
"Component Fault
Management" on page 120
Chapter 5 • Servicing FRUs 109
