This section describes installing the SAS expander cable in Oracle Database Appliance Version
1.
1. Reconnect the SAS expander cable.
a. Reconnect the SAS expander cable connectors to the motherboard [2].
b. Position the server node's front cover onto the server node and tighten
the three green, captive Phillips screws that secure the server node's front
cover to the motherboard [1].
2. Return the server node to operation.
a. Install the PCIe riser.
See "Install PCIe Riser in Server Nodes" on page
b. Install the server node top cover.
See "Installing the Server Node Top Cover" on page
Install the server node into the system.
c.
See "Installing a Server Node Into the System Chassis" on page
Power on the server node.
d.
See "Powering On Oracle Database Appliance Version 1" on page

Servicing the Boot Disk Backplane Cables (FRU)

Information in this appendix does NOT apply to Oracle Database Appliance X3-
Note -
2, Oracle Database Appliance X4-2, Oracle Database Appliance X5-2 or Oracle Database
Appliance X6 series. Refer to the preceding chapters in this document for information on
servicing those systems.
The Oracle Database Appliance Version 1 boot disk backplane cables connect the boot disk
backplane to the motherboard.
The boot disk backplane cables are FRUs and can only be replaced by an Oracle-qualified
service technician.
The following topics are covered in this section:
179.
245.
Appendix A • Servicing the Oracle Database Appliance Version 1
Install SAS Expander Cable
246.
