Oracle Database Appliance X7-2-HA Status Indicators
Callout
10
Oracle Database Appliance X7-2-HA Storage Shelf
Indicators
Storage shelves are supported with Oracle Database Appliance X7-2-HA. They include controls
and indicators on the front panel, hard drives, SSD drives, power supplies, and SAS I/O
modules.
Storage Shelf Front Panel Status Indicators
The following figure shows the controls and indicators on the for the Oracle Database
Appliance X7-2-HA storage shelf (DE3-24C) front panel and drives.
Note -
not used with the Oracle Database Appliance product. Any numbers or letters displayed in this
panel other than zeros could indicate a fault with either the panel, its cabling (neither of which
are customer replaceable), or some other storage shelf component.
20 Oracle Database Appliance Service Manual • November 2017
Indicator/LED: Color
server. When using an SFP28
port, network connectivity is
disabled on the 10GbE RJ-45
ports (NET 1 and NET 2).
NET 1 and 2 10/25 GbE SFP28
ports: green/amber
Note - The 10/25 GbE SFP28
(NET 1 and NET 2) ports are
the default network ports for the
server. When using an SFP28
port, network connectivity is
disabled on the 10GbE RJ-45
ports (NET 1 and NET 2).
The 2 or 3 character LED enclosure ID display panel on the front of the storage shelf is
State Meaning
■ Off – No activity.
■ Flashing – Packet activity.
Top right speed indicator:
■ Off – 10/100BASE-T link (if link up).
■ Amber On – 1000BASE-T link.
■ Green On – 10000BASE-T link.
10/25 GbE SFP28 interface.
Top activity indicator:
■ Off – No activity.
■ Flashing – Packet activity.
Bottom speed indicator:
■ Off – No activity.
■ Amber On – 10GbE link.
■ Green On – 25GbE link.
