Install PCIe Card Cables for Secondary HBA PCIe Card
Install PCIe Card Cables for Secondary HBA PCIe Card
Note -
2, Oracle Database Appliance X4-2, Oracle Database Appliance X5-2 or Oracle Database
Appliance X6 series. Refer to the preceding chapters in this document for information on
servicing those systems.
This section describes installing secondary HBA PCIe card cables in Oracle Database
Appliance Version 1.
Reconnect the PCIe card cables.
1.
a. Reconnect the two PCIe card cables between to the secondary PCIe card
and the connectors on the motherboard [2].
The Secondary HBA PCIe Card sits in the top slot on the PCIe riser (PCIe slot 2)
Notice that there are two sets of connectors on the motherboard. Be sure to connect the
cables to connector on the left in each set (looking at the connectors from the rear of the
server node).
b. Position the server node's front cover onto the server node and tighten
the three green, captive Phillips screws that secure the server node's front
cover to the motherboard [1].
Return the server node to operation.
2.
Install the server node top cover.
a.
See
b. Install the server node into the system.
See
c. Power on the server node.
See
234 Oracle Database Appliance Service Manual • November 2017
Information in this appendix does NOT apply to Oracle Database Appliance X3-
"Installing the Server Node Top Cover" on page
"Installing a Server Node Into the System Chassis" on page
"Powering On Oracle Database Appliance Version 1" on page
245.
246.
249.
