Oracle Database Appliance X7-2M Service Manual page 148

Remove a Server Node From the System Chassis
Note -
performed by an Oracle-qualified service technician. The customer may remove the server node
to service other CRU components in the server node.
Shut down the server node.
1.
See "Shut Down a Server Node" on page
Caution -
shutdown unless it is an emergency.
2. To unseat the server node from the system chassis, pull the two latches on the
rear of the server node down [1].
The latches are marked by green tabs. Pull the latches down and away from the rear to the
system.
3. Slide the server node to the rear and lift it out of the system [2].
148 Oracle Database Appliance Service Manual • November 2017
Replacing a server node FRU with a new server node is a service activity that must be
Data loss. To avoid data loss and file system corruption, always use a graceful
143.
