Oracle Database Appliance X7-2M Service Manual page 22

Oracle Database Appliance X7-2-HA Status Indicators
Callout
8
Storage Shelf Back Panel Status Indicators
The following figure shows the controls and indicators on the Oracle Database Appliance X7-2-
HA storage shelf (DE3-24C) back panel and drives.
Callout
1
2
22 Oracle Database Appliance Service Manual • November 2017
Indicator/LED: Color
Power/Activity: green
Indicator/LED: Color
AC power fault indicator: amber
Fan fail indicator: amber
State Meaning
■ On – The drive is installed and recognized by the system but
there is no drive activity.
■ Blink – The LED blinks randomly in response to data being
written to or read from the drive.
■ Off – The drive is powered off or the installed drive is not
recognized by the system.
State Meaning
■ On – Indicates an AC power fault.
■ Off – Normal operation.
■ On – The fan is faulty.
■ Off – Normal operation.
