Remove a Storage Drive
Drive Slot Numbers and
Types Supported
HDD0
Server Node boot drives. Each appliance server node contains two boot drives that are
installed in the back of Oracle Database Appliance and identified on the rear drive panel label.
The following table shows the location and numbering of the boot drives.
Callout
1
2
Remove a Storage Drive
Note -
2, Oracle Database Appliance X4-2, Oracle Database Appliance X5-2 or Oracle Database
Appliance X6 series. Refer to the preceding chapters in this document for information on
servicing those systems.
154 Oracle Database Appliance Service Manual • November 2017
Drive Slot Numbers and
Types Supported
HDD1
Drive Locations and Identification
Boot Drives at the back of server node 1. Location and identification of the server node 1 boot drives as
listed in Oracle ILOM:
■ /SYS/MB/RHDD1
■ /SYS/MB/RHDD0
Boot Drives at the back of server node 0. Location and identification of the server node 0 boot drives as
listed in Oracle ILOM:
■ /SYS/MB/RHDD1
■ /SYS/MB/RHDD0
Information in this appendix does NOT apply to Oracle Database Appliance X3-
Drive Slot Numbers and Drive Slot Numbers and
Types Supported Types Supported
HDD2 HDD3
