If you added 10 TB HDDs to the shelf (and moved the existing 3.2 TB SSDs), perform
■
cleanup, redeploy the appliance and restore the database as described in the Deployment and
User's Guide for the appliance.
3. If you are also adding a storage expansion shelf, you can do so now.
Refer to the Oracle Database Appliance Deployment and User's Guide for information on
attaching and cabling a storage expansion shelf.
Adding Optional Oracle Database Appliance X6-2-HA Storage
Shelf Drives (CRU)
The Oracle Database Appliance X6-2-HA storage shelf base configuration (half-
Before You Begin ■
populated) supports ten expansion slots for 1.6 TB SSD drives. These are slots labeled 10-
19 as seen from the front of the system (callouts 10 through 19 in the following illustration).
When adding to the storage shelf, you must populate all of these slots at the same time. This
upgrade can be performed with the appliance running.
Note -
all the new disks at the same time. Once you expand storage to support disks in slots 10-19,
you cannot revert to the base configuration (no drives in slots 10-19).
In addition, you cannot add a storage expansion shelf to your appliance configuration until
you have fully populated the existing storage shelf.
The oakcli commands listed here must be run as the root user.
■

Adding Optional Oracle Database Appliance X6-2-HA Storage Shelf Drives (CRU)

If you expand storage, you must first add all of the disks and then expand storage on
Chapter 3 • Servicing CRUs That Do Not Require System Power Off 83
