Oracle Database Appliance X7-2M Service Manual page 236

Install SAS Expander Cable
See
d. Remove the PCIe riser.
See
Disconnect the SAS expander cable and remove it from the server node.
2.
a. Loosen the three green, captive Phillips screws that secure the server
node's front cover and remove the cover [1].
Disconnect both cable connectors from the motherboard and remove the
b.
cable [2].
Push the connector inward, press down on the connector to release it, and pull the
connector out.
Install SAS Expander Cable
Note -
2, Oracle Database Appliance X4-2, Oracle Database Appliance X5-2 or Oracle Database
Appliance X6 series. Refer to the preceding chapters in this document for information on
servicing those systems.
236 Oracle Database Appliance Service Manual • November 2017
"Removing the Server Node Top Cover" on page
"Remove PCIe Riser From Server Nodes" on page
Information in this appendix does NOT apply to Oracle Database Appliance X3-
149.
178.
