Chapter 4 – General Configuration
The MultiLoad II is capable of communicating with up to 10 slave devices using the Modbus protocol. Once the
device has been configured, you can then use
To configure the settings for these devices, you must select Device Configuration from the Modbus Setup
screen.
Then select a device you wish to configure.
Firmware Version 3/4.31.37
Custom Logic
MODBUS SETUP
Modbus TCP/IP Port(502):
Modbus 32-Bit Little Endian:
Device Configuration_____________________
Next Prev
SELECT MODBUS DEVICE
#1 (Device 01
#2 (Device 02
#3 (Device 03
#4 (Device 04
#5 (Device 05
#6 (Device 06
#7 (Device 07
#8 (Device 08
#9 (Device 09
#10(Device 10
Next Prev
to send read and write commands.
ENABLED
DISABLD
Exit Enter
)
)
)
)
)
)
)
)
)
)
Exit Enter
