Chapter 5 – Product Flow Control
The Dead Band rates for the flow stages are configured on the Meter Setup screen. No valve adjustments will be
attempted when the flow rate is within the dead band. Whenever flow drifts outside of the dead band, the valve
will make adjustments to bring the flow rate back within the dead band. If multiple meters are assigned to the
preset, repeat this process for the other meters.
Two additional ratio blending parameters are found on the Meter Setup screen. The Ratio Adjust Proportional
Factor and the Ratio Adjust Derivative Factor have been configured at the factory. These parameters should not
be adjusted without consulting Toptech Systems.
Firmware Version 3/4.31.37
PRE #1 MTR #1 SETUP
Flow Control Module#:
Side-Stream on Mtr#
Side-Strm on Any Mtr#
Meter Address:
Meter Type:
Max Quad Errors:
Reset Quad Errors:
Low Flow Alarm Rate:
Low Flow Alarm Time:
Excess Flw Alrm Rate:
Minimum Flow Rate:
Maximum Flow Rate:
Low Flow DB Rate:
High Flow DB Rate:
Next
Parameter
Flow Control Module #
1st Stage Dead Band Rate
2nd Stage Dead Band Rate
DISABLD
VOL PUL
10.000
Prev
Exit
Enter
Default Setting
0
40 gallons per minute
40 gallons per minute
0
0
0
10
10000
10
800
50
650
40
40
183
