Chapter 9 – Weights & Measures
8.2 C R
ARD EADER
Note: If the MultiLoad II is a SMP or does not have a card reader installed, this test is not applicable.
Use the Card Reader function to verify the operation of proximity card reader and a driver card.
From the DIAGNOSTICS MENU, choose Card Reader.
The Card Reader Test screen displays. After placing a card in the reader card holder the screen will update after
each read of the card.
The diagnostic data reported is:
Good Reads – Number of times a successful read of the card is performed. This value should increment
-
approximately once every second while a card is inserted.
Card Pulls – Number of times a card has been removed from the card reader.
-
Parity, LRC, Timeouts – Number of times a certain read error has occurred. These values should remain
-
zero.
For HID 26-bit Prox Cards, 0=yy=0000000=xxxxxxxx=01 – Card number that was read from the card.
-
Where:
yy is the facility number (00-99)
xxxxxxxx is the card number (00000000-00065535).
For HID 26-bit Corporate 1000 Prox Cards, 0=yyyy=00000=xxxxxxxx=01 – Card number that was read from
-
the card.
Where:
Firmware Version 3/4.31.37
(E SMP)
XCLUDING
D I A G N O S T I C S
Card Reader
COM Loopback
Serial Ports
Network Test
Keypad
Display
Unicode
FCM Com
PCM Com
FCM Health
PCM Health
RCU
Bay
Preset
Next Prev
CARD READER TEST
Good Reads: 00005 Card Pulls:
Parity: 00000 LRC: 00000 Timeouts: 00000
0=75=0000000=00035937=01
Good Read – No Error
Exit
M E N U
Meters
Components
Additives
Sampler
Tanks
Custom Logic
Exit Enter
00000
Clear
243
