Chapter 16 – Firmware Revision History
Added new W&M RCU Setup parameter "Use Hundredths", R030, to enable display,
recording, and totalizing in hundredths.
Added support to transaction archive and alibi log for viewing or printing whole
units or hundredths.
Updated Transaction Detail view screen to display whole units or hundredths.
Corrected ticket printing of leading zeros on temperature, pressure and density.
Updated Serial and Modbus interface for totalizers, transaction archive to return
implied two decimal places when the "Use Hundredths" parameter (R030) is enabled.
Updated firmware version to 3.29.03.
12/14/09 3.29.04 WJP
Added API tables 60o and 901A for TTE.
Updated firmware version to 3.29.04.
12/15/09 3.29.05 WJP (merge with Atmel development)
Updated firmware version to 3.29.05
12/16/09 3.29.04 WJP
Correct remote picklist processing to setup default colors when picklist is
written. Bug caused picklist items to appear with black foreground and black
background when host displayed a picklist.
up and first time entering program mode.
would display correctly.
displayed items were black.
2/23/10 3.29.06 WJP (Beta Release to Sam Yu)
In MAC address setup, allow specification of most resent IEEE assigned MAC
address block.
Include NanoSleep() call in Linux simulator build to prevent idle task starvation.
Updated firmware version to 3.29.06
Added Chinese language to product.
Started adding eMail support.
Todo: add registers for email settings.
Increased configuration prompt string from 30 to 45 bytes (max 30 ASCII
characters or 15 UTF-8 characters 3-byte each).
Increased language prompt string from 40 to 60 bytes (max 40 ASCII characters or
20 UTF-8 characters 3-byte each).
Added HTTP server.
Added, for now, English product graphics for Portuguese and Chinese.
4/14/10
Added Conoco Farmington density alarm timeout modification for air in line. Only
time timeout when not in alarm and authorized to allow time for correct density to
be read.
4/30/10 3.29.06 WJP (ILTA Demo)
ILTA Mass Meter Demo Code
Updated Krohne meter diagnostics to include more registers.
Update FCM control logic to deal with mass meter flow with on/off valve for
demo.
5/5/10 3.29.20 WJP (release to QA)
Merge of parallel development streams back into one!!!
Added Mandarin language.
Changed all variable flags from char to int to improve efficiency.
Changed all string usage of "unsigned char" to "char" for compiler compatibility.
Started email functionality development.
Firmware Version 3/4.31.37
Problem would only occur between power
Once program mode was entered, picklist
Picklist would always appear on RCU ditto even when
