Chapter 5 – Product Flow Control
Whenever the flush component is being delivered outside of the flush stage, the minimum flush requirement on
the Status screen will return to zero, as the Line Flush Minimum Volume is achieved. This register immediately
increases to the Line Flush Minimum Volume value as soon as any non-flush component is delivered into the line.
Consider the example of a sequential blend where component #1 is the flush component but the load is aborted
during component #1 delivery; component #2 nor the Flush is delivered. Although technically the flush never
occurred, the Flush feature will not alarm since it knows that the line is filled with component #1, which happens to
be the flush component. The alarm will not activate, provided that the minimum flush requirement was met during
component #1 loading.
To deactivate the Line Flush feature, set the values of the first three parameters in the table below to zero. The
remaining flush parameters are related to blending.
Parameter Name
Line Flush Volume
Line Flush Minimum Volume
Line Flush Component #
Take Line Flush From Match
Take Line Flush From First
Take Line Flush From Last
Line Flush and Blending
When blending multiple components through a load arm, one of the product components will have to be shorted
by a volume equal to the Line Flush Volume. There are three Line Flush parameters that can be configured to
determine which component is shorted. The MultiLoad will consider each parameter in the order that it is listed in
the table above. If the conditions of the first parameter do not resolve the question of which parameter to short,
the parameter that follows the first will be considered, and so on.
The first decision parameter is Take Line Flush From Match.
MultiLoad to determine if the flush component is used in the product. If the Flush Component is used in the
product, it will short that component by the Line Flush Volume amount. The deficit will be made up during the
Line Flush stage. If the flush component is not used in the product recipe or if the parameter is disabled, the
MultiLoad will look to the next parameter for instruction.
The second decision parameter is Take Line Flush From First. This decision will be considered if the previous
parameter is disabled or if the previous decision was not resolved. If this parameter is enabled, the MultiLoad will
Firmware Version 3/4.31.37
PRE #1 (Preset 001) SETUP
Line Flush Vol:
Line Flush Min Vol:
Line Flush Comp#:
Take L.F. from Match:
Take L.F. from First:
Take L.F. from Last:
Alf. High Delay:
Stop Start Delay:
Blnd Chk Start Vol:
Blnd Chk Restart Vol:
Blnd Chk Alarm %:
Blnd Chk Alarm Vol:
Blnd Chk Alarm Time:
Blnd On Lead Comp:
Next Prev
Default Setting
0 gallons
0 gallons
0 (no component selected)
Enabled
Disabled
Disabled
0
0
0
ENABLED
DISABLD
DISABLD
0
0
60
10
%5.00
25
10
DISABLD
Exit Enter
Screen Location
Preset Setup
Preset Setup
Preset Setup
Preset Setup
Preset Setup
Preset Setup
This parameter, if enabled, will instruct the
