Chapter 4 – General Configuration
Parameter
Alarm High API Gravity
API Gravity Alarm Time
API Gravity @ Low
Value
API Gravity @ High
Value
API Gravity Offset
C
4.8.4
OMPONENT
Use the Component Setup functions to configure the characteristics of a component.
Further details about flow control can be found in Chapter 5.
Component flow rates are configured in the Weights & Measures -> Component section and can be found in
Chapter 8.
Navigate to this screen as: Program Mode -> Configuration -> Equipment Setup -> Select Parameter Level ->
Components
The Component Setup screen displays:
Parameter
Meter #
High Flow Rate
Firmware Version 3/4.31.37
Description
When an API Gravity Sensor is enabled, this parameter can be used to raise an alarm
when the measured API Gravity rises above a maximum value. When the API Gravity
of the metered product exceeds the value entered in this field, an API Gravity alarm
will be raised and loading will be stopped. See API Gravity Calibration for instructions
on configuring an API Gravity sensor.
At the default value of zero seconds, API Gravity alarms will be raised instantly. A
small delay can be added, in seconds, to avoid nuisance alarms that may occur when
API Gravity is momentarily out of range. The API Gravity alarm timer will only run
when an API Gravity alarm is not active and a batch is currently authorized on this
preset.
Enter the API Gravity that will represent the lowest API Gravity value measured by the
transmitter. This value will be equal to 4 mA or 1V.
Enter the API Gravity that will represent the highest API Gravity value measured by
the transmitter. This value will be equal to 20 mA or 5V.
This parameter provides a means to introduce an API Gravity offset to correct the
indicated API Gravity to the observed API Gravity.
S
ETUP
PRE #1 CMP #1 (Base 001
Meter#:
High Flow Rate:
1st Stage Trip Vol:
1st Stage Flow Rate:
2nd Stage Trip Vol:
2nd Stage Flow Rate:
Final Trip Vol:
Final Trip Max Time:
Final Trip Vol Lock:
Unauth Flow Alrm Vol:
W&M Recipe Percentage:
BlkValve Open Rate:
BlkValve Open Delay:
B.V. Open Alrm Time:
Next Prev
Action
Assign the component to a flow meter.
Set to the same value as the high flow rate in the preset menu. It may be a different
value if piping requirements dictate.
) SETUP
1
600
70
225
20
150
1.15
5.000
DISABLD
10
%0.00
0
0
10
Exit Enter
