Timers/Counters - Toptech Systems MultiLoad II User Manual

Chapter 13 – Custom Logic
T
13.2.6
IMERS
The Timers/Counters group can be used to delay outputs, send pulses, and create trigger able counters.
Type
Start Delay
Stop Delay
Beacon
Pulse
Counter
Firmware Version 3/4.31.37
/C
OUNTERS
SELECT CUSTOM LOGIC TIMER PARAMETER
START DELAY
STOP DELAY
BEACON
PULSE
COUNTER
SET/RESET
Next
Inputs
A.) Custom Logic Index
B.) Custom Logic Index
A.) Custom Logic Index
B.) Custom Logic Index
A.) Custom Logic Index
B.) Custom Logic Index
A.) Custom Logic Index
B.) Custom Logic Index
A.) Custom Logic Index
B.) Custom Logic Index
C.) Custom Logic Index
Prev Exit Enter
The output is initially 0. Once the trigger goes to 1,
then the output will become 1 after the delay time.
- Input A is the trigger which will start the timer.
When the trigger goes to 0 the output will be 0.
- Input B is the delay time, in seconds,
The output is initially 1. Once the trigger goes to 0,
then the output will become 0 after the delay time.
- Input A is the trigger which will
When the trigger goes to 0 the output will be 0.
- Input B is the delay time, in seconds,
The output continuously pulse from 0 to 1.
- Input A is the amount of time, in seconds, in
which the output will stay at 1.
- Input B is the amount of time, in seconds, in
which the output will stay at 0.
The output is initially 0. Once the trigger goes to 1,
then the output will become 1 for a specified amount
of time.
- Input A is the amount of time, in seconds, in
which the output will stay at 1,
- Input B is the trigger which will
and set the output to 1.
The output will increment by one every time input A is
triggered, and will decrement by one every time input
B is triggered. It will be reset when input C is
triggered.
Description
start the timer.
start the timer,
415
