Chapter 13 – Custom Logic
Parameter
Card 1 Number
Card 1 Facility Code
Card 2 Number
Card 2 Facility Code
Security Bypass
Config Changed
Bay Real Time (RT)
Parameter
Clearing Errors
Diagnostic Mode
All Stop
Alarm Out
Authorized
Permissive Out
Permissive 0 – 7
Deadman Input
Deadman Output
Deadman Bypass
Total Volume
Start Transaction
Stop Transaction
Total Net Volume
Firmware Version 3/4.31.37
Gives the card number of the loader
Gives the facility code of the loader
Gives the card number of the security card
Gives the facility code of the security card
Indicates if the Security Bypass switch is ON or OFF
Indicates that the MultiLoad is in Program Mode and a parameter has been
changed.
Indicates that operational alarms are being cleared. This process can be
initiated remotely or locally.
Indicates when the operator has entered a diagnostic screen.
Indicates when the ALL Stop button has been pressed.
Indicates when a Bay Level alarm, such as a permissive, has been
triggered.
Indicates when a driver has successfully completed the authorization
process and is able to load.
Indicates that all Bay Level permissives have been satisfied.
Monitors the state of that specific permissive.
Looks to the FCM port number assigned to the Deadman Input parameter
and indicates the current state.
Indicates when the Deadman warning timer has expired and the Deadman
Output signal will be triggered.
Indicates the current state of the Deadman Bypass FCM input.
Total Gross volume delivered of the current load for the entire Bay.
Indicates the current state of the Start Transaction FCM input.
Indicates the current state of the Stop Transaction FCM input.
Total Net volume delivered of the current load for the entire Bay.
Description
Description
