Chapter 4 – General Configuration
D
4.14.3
EFINING A
Defining a sampler is almost identical to defining a base component:
On the Product Selection screen, highlight the product to edit.
Press Enter will select the product to edit.
The Edit Product screen displays:
Fill in the fields as you did for the base component, but with one exception: For Type, select Sampler, as shown
in the sample below.
Firmware Version 3/4.31.37
S
AMPLER
PRODUCT SELECTION
Comp: 000123 BASE87UNL
Comp: BAS002 Base 002
Comp: BAS003 Base 003
Comp: BAS004 Base 004
Comp: BAS005 Base 005
Comp: BAS006 Base 006
(------undefined------)
Samp: SAM001 Samp 001
Samp: SAM002 Samp 002
Samp: SAM003 Samp 003
Samp: SAM004 Samp 004
Samp: SAM005 Samp 005
Samp: SAM006 Samp 006
(------undefined------)
Next Prev
EDIT PRODUCT
Code : SAMP720
Long Desc : SAMPLER LZ1
Short Desc: SAMP0720
Hazard Idx: 0
Type : Sampler
Edit Product Recipe
Next Prev
Exit Enter
Exit Enter
150
