Toptech Systems MultiLoad II User Manual page 341

Chapter 10– Views and Inquiries
Bol# Bol # sequence number from MultiLoad II
Detail Number of details of 1 transaction (1 to 99)
Batch# Batch# sequence number from MultiLoad II for each loaded batch the number will be
increased by 1
Preset Preset or Arm which was used during loading
Component Component which is loaded
Type Product Type: 1=Saleable Product Recipe; 2=Component; 3=Additive; 4=Meter,
5=Preset Totalizer, 6=Meter Totalizer, 7=component Totalizer, 8=Additive Totalizer
Product Name of the Product (Saleable, Component , Additive)
Alarm If their was an alarm for that transaction
Gross Gross Volume.
Net Net Volume.
Mass Mass
Temperature Temperature of the load
Pressure Pressure of the load
BSW Bottom Sediment Water (percentage %)
Density Density of the load
Relative Relative Density of the load
Density
API Gravity API Gravity of the load
API Table Name of the API-table that is used for that batch
Vcf Vcf- factor which is used during the loading
Ctl Temperature correction factor
Cpl Pressure correction factor
Firmware Version 3/4.31.37
VIEW TRANSACTION DETAIL DETAILS
Bol#: 00001 Detail#:
Batch#: 0000005
Preset:
Type: Preset Product:
Alarm:
Gross: 499.54 Net:
Mass: 0.0
Temperature:
Pressure:
BSW:
VCF(None):
CTL: 1.0000 CPL:
Next Prev
00001
01 Component:
PRD001
No
499.54
+28.5
+0.0
+0.0
1.0000
1.0000
Exit Enter
01
341
