Chapter 16 – Firmware Revision History
06/26/08 3.28.10 WJP
Fixed bug that caused the output pulse configuration to incorrectly reserve port
1 (on IO boards should be port 10) and raise a configuration alarm when anything
else was assigned to the port.
Since output pulse can be on port 1 (fcm) or 10 (io board), and it is not known
what board is attached do not report output pulse assignment conflicts.
07/17/08 3.28.10 WJP
Added ml_gps.c to build to support GPS operations.
To support the building of a Linux ML simulator task,
Updated Makefile to build a Linux ml_sim executable.
SIMULATE precompiler definition will be used to enable simulation code.
SIMULATE will exclude MAC address viewing and modification.
SIMULATE will include a driver to display the virtual display on the screen.
SIMULATE will include FEXIT command to save NVRAM and terminate application.
SIMULATE will include command line switches to supporting enabling the terminal
display, keypad, device address and device socket port.
07/28/08 3.28.11 WJP (released to Measurement Canada)
Updated firmware version to 3.28.11.
08/27/08 3.28.12 WJP (released to G.R.)
Correct bug in U133 that prevented access to FCM ports over 7.
Corrected bug in uploadable logo size on SMP that prevented uploading new
customer logos.
Updated firmware version to 3.28.12.
09/5/08 3.28.12 WJP
Updated makefile to build new MultiLoad II Mobile application.
Added new "MultiLoad II Mobile" product identification graphic.
R000 will respond with "MultiLoad Mobl" to identify MultiLoad II Mobile
product.
The following are specific only to the MultiLoad II Mobile product.
Added GPS selection in Communication Setup display.
Setup default serial configuration to have GPS on COM1 and Printer on COM2.
Added GPS Diagnostic screen under the Diagnostics Menu.
Added GPS Site Database to store up to 4,000 site names with Lat/Log
position.
Added GPS Site Setup screen under the Configuration Menu.
Added new RCU level parameter "Max GPS Site Distance".
must be within this number of meters of a site in the GPS Site Database.
number is zero, location verification is not performed.
Added new "*GPS Err" alarm.
seconds. Also raised when a transaction is authorized and the authorization
position is not at a site in the GPS Site Database or the current position has
moved from the site where authorization was obtained.
Updated logic to place Site Name, Latitude and Longitude information into the
last three transaction prompt fields.
Updated duplicate ticket message will appear on left margin for small ticket
size.
Setup default ticket configuration for a small ticket size with Site,
Latitude, and Longitude information.
Updated idle screen to display Latitude, Longitude, Speed, Heading, and Site
Name.
Updated Transaction Archive Header Screen to display entire length of 4 prompts
to show Lat and Long information.
Firmware Version 3/4.31.37
Alarm raised when no GPS fix data arrives for 60
The current position
If this
