Chapter 16 – Firmware Revision History
09/03/2013 PS
PHASE1: Moved BSW from meter level to preset level, this includes communication
(smith to Modbus), BSW removed from component screen, added a second
BSW to support two ranges of inputs, calculations, view and inquire BSW1 and 2
screens.
Enhancement add full logic to support 2 BSW values at the same time, includes
also diagnostic purpose, only one of the two will be available
at the communication level.
PHASE2: Add watercut formula and make the call to it.
09/04/2013 PS
Enhancement let fcm output configuration parameters link to custom logic with the
internal input value.
Enhancement let external communication systems send values to MTL2, which can be
linked to custom logic with the external input value.
Update communication protocols so external systems can write via all protocols to
custom_logic_values.
09/05/2013 PS
Enhancement of all input and output configuration permissives so they can be
inverted, instead of doing this in custom logic.
Fix that custom logic parameter set_value can it also can be updated with a
negative value over communication.
Fix in Access ID Screen the check if a driver record is empty.
09/06/2013 PS
Enhancement move trace configuration under new menu and register 108.
Added new trace menu screen, with out of range checking at boot up.
Added storage of these values on the sd-card.
Added register 108 to all protocols, not Modbus.
Rename all trace references in the code.
09/09/2013 TF
Added the ability to view, rename, create, and delete a file or directory on the
SD Card.
Fix when going in and out of directories shows the proper page and cursor
placement.
Fix when renaming or saving a file only pressing the ENTER key will actually save
the file.
09/09/2013 PS
Fix to show in the webpage rcuditto screen the sign > and <.
09/11/2013 PS
Phase2: Enhancement add correct battery voltage to the RCU Diagnostic screen.
09/20/2013 PS
Phase3: Added serial flash storage of total off time as a check value.
Added battery capacity calculations.
Adjustment on compensation voltage and temperature reading.
09/23/2013 TF
Added a conformation screen when setting factory defaults on power up using the
CLR key that asks the user to press '1234' to continue. If any other key (except
the CLR key) is pressed, then setting factory defaults is aborted.
09/25/2013 TF
Firmware Version 3/4.31.37
