Chapter 13 – Custom Logic
R
13.2.3
EAD
The Read/Write Configuration groups are used to read and/or write the configuration parameters of the MultiLoad.
Reading a parameter will put the value of that parameter into the selected line custom logic line.
Firmware Version 3/4.31.37
Gross Delivered
Pacing Rate
Current Target
Sampler State
/W C
RITE ONFIGURATION
SELECT CUSTOM LOGIC READ PARAMETER
Next
Indicates the current gross volume delivered, of the
specified sampler, for the current batch. Value is in
thousandths with an implied decimal.
Indicates how often a sample will be taken for the
current batch, as defined by the product recipe. Value
is hundredths with an implied decimal
Indicates the current target number of injections, of the
specified sampler, for the current batch.
Indicates the current state of the specified Sampler.
Each state will be represented as a numerical value
(see below).
Inactive
Ready
Sampling
P
ARAMETERS
RCU CFG
BAY CFG
PRESET CFG
COMPONENT CFG
METER CFG
ADDITIVE CFG
SAMPLER CFG
Prev Exit Enter
State Numeric Value
403
0
1
2
