Chapter 5 – Product Flow Control
Weights & Measures - Meters
Minimum Flow Rate 5 gpm
Maximum Flow Rate 100 gpm
5.6 H B
YBRID
The MultiLoad architecture permits hybrid blending schemes, where there may be multiple side-streams or
multiple, major components that flow through the primary stream.
M
5.6.1
ULTIPLE
Since five flow meters can be assigned to one load arm, it is possible to have multiple side-streams serving a
primary meter. The key to supporting multiple side-streams is designating meters as side-stream meters when
performing the meter-level configuration.
Firmware Version 3/4.31.37
Figure 5.6
(E
LENDING XCLUDING
S -S
IDE TREAMS
P
Comp #1
T2
P Comp #2
M2
T3
P
Comp #3
Figure 5.7
Simple Side-Stream Configuration
SMP)
T1
CV
M3
CV
Multiple Side-Stream Application
M1
CV
186
