Diagnostic mode—A PPPoE session is established immediately after the device
configurations finish. The device automatically terminates the PPPoE session and then tries to
re-establish a PPPoE session at a pre-configured interval. By establishing and terminating
PPPoE sessions periodically, you can monitor the operating status of the PPPoE link.
The PPPoE session operating mode is determined by your configuration on the dialer interface:
•
Permanent mode—Used when you set the link idle time to 0 by using the dialer timer idle
command and do not configure the dialer diagnose command.
•
On-demand mode—Used when you set the link idle time to a non-zero value by using the
dialer timer idle command and do not configure the dialer diagnose command.
•
Diagnostic mode—Used when you configure the dialer diagnose command.

Configuring a dialer interface

Before establishing a PPPoE session, you must first create a dialer interface and configure bundle
DDR on the interface. Each PPPoE session uniquely corresponds to a dialer bundle, and each dialer
bundle uniquely corresponds to a dialer interface. A PPPoE session uniquely corresponds to a dialer
interface.
For more information about configuring dialer interfaces, bundle DDR, and dialer bundles, see
"Configuring DDR."
Configuring a dialer interface for a PPPoE client
Step
1. Enter system view.
2. Create
group and configure a dial
access control rule.
3. Create a dialer interface and
enter its view.
4. Assign an IP address to the
interface.
5. Enable bundle DDR on the
interface.
6. Associate the interface with
the dial access control rule
by associating the interface
with
dialer access group.
7. Configure
timeout timer.
8. Configure
application to operate in
diagnostic mode.
9. Set the auto-dial interval.
Command
system-view
a dialer access
dialer-group
{ protocol-name { deny | permit } | acl
{ acl-number | name acl-number }
interface dialer number
ip
ppp-negotiate }
dialer bundle enable
dialer-group group-number
the corresponding
the link-idle
dialer timer idle idle [ in | in-out ]
the DDR
dialer diagnose [ interval interval ]
dialer timer autodial autodial-interval
dialer-group
address { address
51
Remarks
N/A
rule
By default, no dialer group
exists.
N/A
mask |
By default, no IP address is
configured.
By default,
enabled.
By default, a dialer interface is
not assigned to any dialer
group.
The default setting is 120
seconds.
When this timer is set to 0
seconds, the PPPoE session
operates in permanent mode.
Otherwise,
session
on-demand mode.
By default,
application
non-diagnostic mode.
When DDR
diagnostic mode, the link-idle
timeout timer is ignored.
The default setting is 300
no DDR is
the PPPoE
operates in
the DDR
operates in
operates in
