Configuring LFI

Real-time packets, such as Telnet and VoIP packets, might be blocked or delayed on a low-speed
interface.
To reduce delays and jitters on low-speed links, LFI fragments large packets into small fragments.
The fragments are reassembled at the destination.
Figure 2 illustrates the LFI process. When large packets and small voice packets arrive at a
WFQ-enabled interface, LFI performs the following operations:
•
Fragments the large packets into small fragments.
•
Adds the fragments to the queues along with the voice packets.
Figure 2 LFI
Large packet
Voice packet
To configure LFI:
Step
1. Enter system view.
2. Enter
interface, or dialer interface view.
3. Enable LFI.
4. Set the maximum LFI fragment
transmission
maximum LFI fragment size (in
bytes).

Displaying and maintaining PPP and MP

Execute display commands in any view and reset commands in user view.
Fragmentation
Traffic
classifying
VT interface, MP-group
delay and the
WFQ
WFQ
Command
system-view
interface { dialer
mp-group
virtual-template
mp-number
ppp mp lfi enable
•
ppp mp
delay-per-frag time
•
ppp mp
size-per-frag size
25
Output queue
Remarks
N/A
|
|
N/A
}
By default, LFI is disabled.
Disabling LFI also removes the
user-configured settings of the
maximum LFI fragment delay and
size.
By default, the maximum LFI
lfi
fragment transmission delay is 10
ms, and the maximum
fragment size is the expected
lfi
bandwidth of the interface times
the maximum delay divided by 8.
LFI
