Configuring An Interface To Receive Calls - HPE FlexNetwork MSR series Configuration Manual

Step
4. Configure a dial string.
5. Return to system view.
6. Enter physical interface view.
7. Assign the physical interface
to a dialer circular group.
8. Configure the priority of the
physical
dialer circular group.

Configuring an interface to receive calls

To configure an interface to receive calls, you only need to enable DDR on the interface.
For the receiving interface to authenticate the caller, configure the dialer route ip next-hop-address
user hostname command. Then, if the IP address and host name of the caller match the configured
ones, the receiving interface accepts the call. Otherwise, it rejects the call.
When you configure an interface to receive calls, follow these guidelines:
•
To configure one interface to receive calls, you can make the configuration on the physical
interface or through a dialer circular group.
•
To configure multiple interfaces to receive calls, you can make the configuration only through a
dialer circular group.
Configuring an interface to receive calls directly on a physical interface
Step
1. Enter system view.
2. Enter physical interface view.
Command
•
•
quit
interface
interface-number
dialer circular group number
interface in the
dialer priority priority
Command
system-view
interface
dialer number dial-number
dialer route
next-hop-address [ mask
network-mask-length
[ vpn-instance
vpn-instance-name
dial-number dial-number
[ interface interface-type
interface-number
[ broadcast ]
interface-type
interface-type
172
Remarks
ip
]
By default, no dial string is
configured.
]
]
N/A
N/A
By default, a physical interface
does not belong to a dialer circular
group.
Make sure the number arguments
in the interface dialer and dialer
circular group commands use
the same value.
The default setting is 1.
When configuring one interface to
place calls, you do not need to
configure this command.
When configuring
interfaces to place calls, you need
to configure this command. Each
time a call is
highest-priority physical interface
available is selected. If one of the
available physical interfaces with
the highest priority is selected, the
interfaces are selected in a
round-robin manner.
Remarks
N/A
N/A
multiple
placed, the
